A treasured textile tool

tool

My textile treasure from The Gambia, the gift of a former student.

When unpacking after teaching at West Dean this week, I noticed one of my favourite tools hadn’t re-appeared from the boxes.  I began to realise how precious the tool was, and kicked myself for being sufficiently stupid to take it out of the studio and risk losing it. The tool is no bigger than a long paintbrush, it’s clearly home-made and would look insignificant to anyone finding it but not ‘in the know’ about what it was. It could have been binned, or slipped beneath a workbench. It might never re-appear.

The tool, used for applying wax, was given to me nearly ten years ago by an inspiring and enterprising young student who left us with very special memories of her. She was on a scholarship studying batik world-wide and she stayed with us for a few days while I showed her how I worked.  She later travelled to The Gambia, and sent me the tool on her return. It has a simply-shaped, graceful wooden handle around the tip of which is wound a casual-looking thick spiral of copper wire. The spiral forms into a tightly-twisted, spout-shaped ‘nib’.

The copper tool can be dipped into hot wax, and because copper is a good conductor of heat the entire wire quickly reaches equal temperature. The coils of the spiral hold a considerable cargo of hot wax, which flows down into the ‘nib’ allowing a controlled drawing to be made in hot wax. Experience has taught me not to start drawing until drip frequency is slow, or wax flows too fast and floods the fabric. The tool looks as though it shouldn’t work, but in fact it’s remarkably effective and one of my studio favourites.

Some time ago I tried to replicate the tool for students in my classes, using copper wire and a substantial twig, or an old paintbrush, for a handle. I have had surprising success with them and I’ve found, for instance, that a narrower gauge wire can form a finer nib. But none of my versions has the grace and integrity of the original, or carries its history. I instinctively choose the Gambia tool when working, even though my replicas work just as well.

The tool was created by people who own little and must labour extremely hard to produce their batik work: they have no electricity, gather wax from bee-hives, heat wax on a fire and carry all their water by hand. Only when I unpacked my boxes and contemplated the possible loss of my student’s gift did I acknowledge (for the first time) that the tool’s story was as important as its function.

Happily, I found it.



Link: This remarkable little book tells the story of Rushyan’s batik journey

Paths of Molten Wax: A Textile Odyssey









Advertisements


Leave a comment

Dyeing Reds in Amsterdam

safflower_edited-1

Safflower petals before washing

I recently took part in a two-day workshop in Amsterdam, dyeing historical reds on silk at the Rijksmuseum’s Department of Conservation and Restoration. The event was organised by the Cultural Heritage Agency of the Netherlands. Selection for the workshop was by application, and the organisers chose eight international participants known for the variety and extent of their expertise in natural dyeing, and / or their interests in historical dye recipes.

A range of 26 samples was produced using American cochineal, kermes, annatto, brazilwood, madder, safflower and lac. Participants worked in pairs dyeing different sets of dyes: my partner was Paula Hohti of Aalto University, Helsinki, where she is Assistant Professor of History of Art and Culture. We dyed three recipes in total: one for lac and two for safflower. Demineralised water was used throughout.

Lac Our lac recipe was adapted from Edelstein’s translation of the 1548 edition of The Plictho of Gioanventura Rosetti. We prepared and used an alum mordant on Day 1, in which the silk rested overnight. The stick lac we were to use had been extracted over the previous three days. On Day 2 we sieved the lac solution and heated it, adding 25% (to weight of dry fabric) cream of tartar. It was dyed for an hour.

lac

Lac-dyed silk being lifted from the beaker to check for colour. On the right is the beaker containing yellow safflower dye and silk

Safflower We dyed two versions of safflower: yellow and red. Our recipes were adapted from various sources, including Macquer’s Art de la Teinture en Soie. To obtain yellow, safflower florets were washed once and drained, and then soaked again for 30 minutes. After sieving, the resulting extract was used to dye unmordanted silk.

safflower

First washing-out of the safflower florets for yellow dyeing

To obtain red, safflower florets were pre-washed for two weeks to remove all traces of the yellow extract – this process had been completed in advance of the workshop.  We undertook a further sequence of washings until the yellow stopped running and the water was clear. The water was sieved out. Potash was added to obtain pH 10, and the florets squeezed by hand until they appeared pink and transparent and the liquor looked pinky red. This took about half an hour to achieve.

After sieving into a new beaker, unmordanted silk was added and the pH checked (it was around 7). We then added fermented beer (bierken) little by little, continually monitoring pH, until the pH dropped to a crucial pH 5. This threshold pH has a term ‘virer le bain‘ or ‘turn the bath’. We were required not to allow the pH to drop lower or it would damage the silk. The silk then rested in the dye for 10 minutes after which it was washed in Marseilles soap, and water.

Both safflower baths produced strong colours, with the pink having an especially bright ‘pop’. The colour is very light fugitive.

3dyes

Safflower red (left), lac (centre) safflower yellow (right

Everyone, including the three organisers, gave short presentations on their work and research interests. I showed some samples of my orchil dyeing as well as a few pieces of my studio work in natural dyes. Many participants were involved in education, some of us were artists and dyers, others were textile researchers or art historians. These absorbing presentations illustrated what a privilege it was to attend the workshop.

The results of the workshop were recently published at the Spring Symposium of the Textiel Commissie.

assort

Participants were able to take away a sample of each recipe dyed: a total of 26 samples

Participants took home a complete set of all the silks dyed. The organisers also retained a set, which will be catalogued and stored as historical reproductions on reference sheets, together with supporting information on the recipes and preparations. The sheets will eventually be published online through the Cultural Heritage Agency (RCE) website, for the benefit of other researchers.


Thanks With many thanks to organisers Drs. Ana Serrano, Jenny Boulboullé and Art Proaño Gaibor; to the Cultural Heritage Agency of the Netherlands; the Ateliergebouw of the Rijksmuseum; and to all fellow participants at the workshop for their unique and specialist contributions.


Links

Rijksmuseum Conservation and Research

Cultural Heritage Agency of the Netherlands

Textiel Commissie

Paula Hohti has recently been awarded a European Research Council grant for a five year project Re-fashioning the Renaissance: Popular Groups, Fashion and the Material and Cultural Significance of Clothing in Europe 1550 – 1650


Leave a comment

Dyes, silk and North Portugal

Bragança

Display board from the Museu do Abade de Baçal, Bragança showing natural dyes once in use for silk dyeing. From top left: Daphne gnidium; indigo; gall nuts; madder; logwood; sumac; soapberry; rosemary; walnut; cochineal; dyers’ broom; Arundo donax (giant cane); ginger; common black alder

I spent most of December in northern Portugal, travelling from the north-east corner of Trás-os-Montes via Miranda do Douro, Bragança and Guimaraēs and, after a visit to Porto, to an area south-west of the extraordinary Peneda-Gerês National Park.

In Bragança’s Museu do Abade de Baçal there was an excellent display on the region’s historic silk industry including an illustrated panel on dyes. There were a few I’ve not heard of, such as Daphne gnidium. In her book Natural Dyes: Sources, Tradition, Technology and Science, Dominique Cardon lists the Daphne in her chapter on flavonoids, which indicates it was a yellow colourant. Cardon offers no local name for it in Portuguese, but the Bragança display gives it the name trovisco. The yellow dye was known in French as trentanel; daphné sainbois; or garou and Cardon notes that the dye came to rival weld in 18th century Languedoc.

The giant cane, Arundo donax, does not appear in Cardon’s book and an internet trawl came up with a few references to its pollen being used to make a yellow dye, but I found no solid information for this.

galls

Oak galls found washed up on the shore at Moledo, near Viana do Castelo

The museum panel also illustrated some large spiky oak galls. I suggest these are of gall wasp Andricus kollari, but please put me right if you think they aren’t. Tannin-rich galls would probably have been used as mordants. I saw these galls on and beneath oak trees in Trás-os-Montes and all across north Portugal, and there were hundreds washed up on the beach near Viana do Castelo.

necklace

Oak galls used as a necklace in man’s costume, from the displays of masks and costumes of the Bragança area at the Museu Ibérico da Mascara e do Traje

Some pre-Christian traditions survive in remoter areas of North Portugal, in the form of rituals that take places at certain times during the year, with men and boys in bizarre costumes and some extremely scary masks. I saw necklaces of oak galls, along with wooden cotton reels, at Bragança’s Museum of Mask and Costume.

Orchil

At the Museu do Abade de Baçal I found one reference to orchil (urzela in Portuguese) as a lichen dye used in the 18th and 19th centuries. I wasn’t overly surprised because I had never seen such profusion of Lasallia pustulata anywhere, and growing to such a large size. The lichen favours granite, the local stone; the air is clear and unpolluted, and the area remains relatively undeveloped. So the lichen grows undisturbed – and long may it continue.

Links

The Silk Industry in Trás-os-Montes During the Ancient Regime: paper by Fernando Sousa, University of Porto

This is a gem of a museum: Museu Ibérico da Mascara e do Traje, Bragança

Excellent display on silk industry: Museu do Abade de Baçal, Bragança


Leave a comment

Wood & Bedford / Yorkshire Chemicals archive


Summary of my presentation to the DHA (Dyes in History and Archaeology) Conference, Hampton Court, October 27th, 2017.


Airedale Works, Kirkstall

The Airedale Chemical Works (Wood & Bedford) around 1850

For the last nine years I have been researching an archive relating to dye manufacture in nineteenth and twentieth century Leeds. In September 2017 a large portion of it was handed over to West Yorkshire Archive Service (WYAS). The archive represents 186 years of a dye manufacturing company’s existence, and covers its life from cradle to grave.

The founding Bedford family has a long and distinguished history of political, social and commercial significance in and around Leeds. The archive is concerned chiefly with their commercial activities, and illustrates how successive generations played an important role in business developments which contributed to the emergence of Leeds as a commercial centre during the nineteenth and early twentieth centuries.

Beginnings In around 1810, a 15-year old James Bedford became apprenticed to a chemist and druggist in Leeds. In 1821 he was involved in oil refining but by 1827 was solely engaged in making cudbear and orchil.  The company ‘Wood & Bedford’ was founded in the 1850s, manufacturing natural dyes and tannins. Wood & Bedford became a leading manufacturer in Leeds, based at premises on Kirkstall Road.

woodbedford

Colophon from after 1850

Wood & Bedford brought together eleven leading local companies in 1900 to form the Yorkshire Dyeware and Chemical Company Limited (YDC). Over the next hundred years this company evolved from being predominantly dependent on natural dyes and extracts to becoming one of the major synthetic dye manufacturers in the world, known for creative ideas and innovative products.

YDC Lorry

Photo from the archive showing YDC lorry. Note the telegram address ‘Dyewood Dewsbury’ on the door!

Yorkshire Chemicals In the twentieth century the company operated under the name ‘Yorkshire Chemicals plc’, signifying its diversification into other chemical classes and acquiring the plc designation when the business floated on the stock exchange in the 1970s.

The textiles industry migrated to Asia, and in the late 1990s the company over-reached itself by acquisition of new companies. Yorkshire Chemicals went into rapid decline, and into administration in 2004. It struggled for another year as Yorkshire Colours under a management buyout, and collapsed again in 2005 when the Leeds factories finally closed. In 2008 the main Leeds sites site were demolished.

The Yorkshire name and brands survive, with the business now under Chinese ownership and continuing to trade in Europe as Yorkshire Farben GmbH based in Germany, and in Asia as Yorkshire Asia Pacific, with headquarters in China.

demoliton 2

Kirkstall Road site under demolition, 2008

Archive sources The archive, which is now housed at WYAS’ Morley facility near Leeds, preserves documentary records and photographs spanning the complete history of a company whose changing fortunes broadly parallel those of the UK and European textiles industry. The collection comprises items from three main sources.

Devon source I live in a small Devon market town. In 2008, a neighbour (who is descended from the Bedfords) invited me to look at a large quantity of family papers and documents. Recognising their historical value, I undertook to find them a permanent home. The items from this Devon source are of the earliest in date, assembled around 1914 by James E. Bedford, at that time Lord Mayor of Leeds.

Demolition Source In 2008 I visited the demolition site in Kirkstall Road and asked to take some photos, explaining my research to the foreman. A fortnight later he called me as his team had found a set of photo albums sealed in to partition wall. These invaluable records now form part of the archive. There are 11 albums, with photographs dating from the 1920s until around 1990.

Muck and brass 1960_edited-1

Photo from one of the 11 albums with a view of Yorkshire Chemicals, 1960s. It has the caption ‘Where’s there’s muck, there’s brass’.

Ex-employee Source Through my research I made contact with a large group of Yorkshire Chemicals ex-employees. Many of them had retained papers, photographs and other documents relating to the latter days of the company which they were happy to donate to the archive. One of these employees has undertaken the colossal task of indexing, annotating  and cataloguing the collection. Future scholars will be indebted to him for his knowledge and insight as a chemist, as a long-serving employee who knew the various sites, subsidiaries and employees, and as an intelligent and often critical bystander to the final company collapse.

Edited 17th January 2018 The catalogue is now online through WYAS. You can start your Search here

A quote from West Yorkshire Archive Service

‘The West Yorkshire Archive Service are delighted to be the new custodians of the Yorkshire Dyeware and Chemical Company Archive, playing our part in preserving the memory of a comprehensive archive of a local business.  The records gives a fantastic insight into the creation, development, success and eventual decline of the company over a 150 year period which will be of great interest to anyone researching the history of manufacturing natural dyes and the evolution of the textile industry in Leeds and we look forward to facilitating public access to the records now, and for generations to come’.

Links

You will find other information on my research, and the archive, by searching the blog using the word cloud.




























Leave a comment

Three historic purples: Tyrian Purple, orchil, and Perkin’s mauveine

dyetrio

Top: blue-purple samples: mauveine-dyed using a shibori technique; lower pair of silks: orchil-dyed in redder shades; threads on orchil-dyed silks: dyed with Tyrian Purple

Here is an image showing an extraordinary trio of historic, and historical, purple dyes. Two are the natural dyes Tyrian Purple and orchil, whose histories are so ancient their origins are unknown. The other dye is a recreated mauveine, the first synthetic dye to be commercially developed, after synthesis in 1856.

All three dyes play a part in an archive I have been researching, which relates to a dye manufacturer based in Leeds. The company began when a young chemist called James Bedford started making orchil and cudbear, later forming a company named Wood & Bedford in around 1850. Through various changes of names and expansions, the company became a major international dye and chemical manufacturer, finally folding in 2004 under the name Yorkshire Chemicals. You can read more about the history by following links below.

Orchil was the natural, lichen sourced dyestuff on which the company’s fortunes were founded by James Bedford. But by the late nineteenth century, William Henry Perkin had discovered and patented his synthetic dye mauveine, signalling the gradual demise of natural dyes in commercial use and the beginning of chemical manufacturing. There was a family connection between the Bedford family and the Perkins’: WH Perkin’s son Arthur G. Perkin married a Bedford daughter. The Leeds company managed to weather the transition from natural to synthetic products and its archives are a fascinating record of how they achieved their success.

As to the Tyrian Purple, perhaps the most unexpected items from the archive are the genuine shellfish-dyed thread samples found in a small envelope. You can see one of the two samples in the image above. Again, please read their story by following links below.

Mauveine dyeings

I was contacted earlier this year by Dr John Plater, a Senior Lecturer in Chemistry at the University of Aberdeen. John has made a study of mauveine and has come to several interesting conclusions about Perkin’s dye. It seems that not all mauveines were / are the same. To read about John’s research, please follow the links below. John had read about my studies in orchil and was curious to know something of the versatility of mauveine in working practice. I sent him shibori-tied silks so that he could experiment with dyeing them, suggesting he try an immersion method on one set of samples, and separately apply dyes with an eyedropper. I find the eyedropper method very successful with synthetic dyes as it gives great control of the dye, and is very economical. You can judge which you think most effective from the page below. Immersion dyed are on the left.

mauveine

The archive’s new home

Later this week I will be presenting a paper at the DHA (Dyes in History and Archaeology) Conference at the Royal School of Needlework, Hampton Court. It will describe the entirety of the Leeds archive, part of which I have been studying. It is now available for public study through the West Yorkshire Joint Services (WYJS) facility at Morley, near Leeds. I will write a separate blog about this after the Conference.

Links

Story of the Leeds Archive on this blog

Tyrian Treasure Part One

Tyrian Treasure Part Two

Dyes, history, and a chilly trip to Yorkshire

Some articles about the work of John Plater:

Detective work uncovers Perkin’s deep understanding of first synthetic dye

Meet the Researcher: free online article from Au Science magazine, (p 21)

Purple’s Reign

‘Accidental chemist’ who brought colour to Victorian society was ‘far ahead of his time’












7 Comments

A Harris Way of Life

Last month I took a ferry to the Western Isles. There is much to say about the wild, bleak beauty of the islands, and their resilient inhabitants, but this is about Harris Tweed and natural dyes.

crotalspoon

Crotal used to scrape lichen from rocks. Marion Campbell collection, Harris Tweed Knitwear at Drinishader

A well-timed tweet from @HTAarchive advised me not to miss a display at the old Drinishader schoolhouse, on Harris. This relates to the life and work of Marion (Morag) Campbell (1909 – 1996) who once lived nearby and had attended the school as a child.

Marion was visited by a Washington Post journalist in the 1990s, telling him, ‘I’m the last person doing it the really old way — dyeing my own fleeces, carding, making my own yarn, weaving — I even do my own ‘waulking’ to clean the tweed and shrink it a bit. That takes a lot of stamping about in Wellington boots!’

scraping crotal

Marion Campbell scraping crotal lichen, probably Parmelia omphalodes or P. saxatilis. Rephotographed at Drinishader. Regret no photo credit available

In a stylish, purpose-built centre behind the school is a contemporary Harris Tweed exhibition called Clo Mhor (The Big Cloth). It is beautifully designed and presented, contains up-to-date examples of catwalk fashion and high quality local design using Harris Tweed.  The Marion Campbell collection, housed off the shop in the schoolhouse itself, could not appear more different. It comprises a number of woven samples, lengths of tweed, photographs, newspaper articles and other items associated with Marion’s long and active life, all assembled in a cramped, higgledy-piggledy fashion and often a bit dusty. It took a little time to absorb, but was rewardingly full of treasures. I found the crotal spoon Marion used to scrape lichen from the rocks, a waulking board, her loom, and dyed but unspun fleece. Marion used only natural dyes in her work, such as peat soot, crotal from various types of lichen, mugwort, logwood and indigo.

Drinishader schoolhouse is well worth a visit and its location on the Golden Road is exceptionally beautiful.

From the Drinishader shop, I bought a copy of Gisela Vogler’s biography of Marion Campbell, first published in 2002. It’s called A Harris Way of Life. A recipe for indigo dyeing puzzled me as it does not appear to explain familiar processes common to all usage of indigo:

indigorecipe

From ‘A Harris Way of Life’ by Gisela Vogler, first published 2002 by Harris Voluntary Service, West Tarbert, reprinted 2006

The description gives no clues as to where and when reduction (removal of oxygen) takes place although the use of stale urine clarifies that the vat will be alkaline. The statement about mordant is curious (because indigo doesn’t need one), as is the phrase ‘making the dye permanent’, and the specific reference to ‘dogleaf’. Dock is sometimes referred to as dogleaf, and is from the Rumex family.

An interesting exchange between various contacts on Twitter took place when I aired the finding on Twitter, and came up with a revelation for which I thank Anna NicGuaire, (or @A_M_Q on Twitter). In Jean Fraser’s book Traditional Scottish Dyes a similar description is included in an indigo recipe from South Uist. It gives sorrel as the ‘mordant’ ‘to make the colour adhere to the wool’.  (Sorrel is Rumex acetosa).

I later found a similar reference in Ethel Mairet’s 1916 book on vegetable dyes, where she states, ‘Some add a decoction of dock roots the last day, which is said to fix the blue. The wool must then be thoroughly washed.’

The function of sorrel or dock is far from clear in any of the three instances, but it will not be acting as a mordant in the standard sense. Dock does appear in several dye publications I have consulted, but as a colourant.

I have great respect for traditional recipes and expect there to be a reason for the sorrel or dock stages as described. I’d be very interested in anyone’s views.

Links

Marion Campbell, BEM

Video of Marion Campbell weaving

David Yeadon’s 1990 account of a visit to Marion Campbell for the Washington Post

Clo Mhor exhibition at Harris Tweed and Knitwear

Thanks

Special thanks to the Twitter community including @HTAarchive, @A_M_Q, @Freyalyn, @ripplescrafts, @TorranIslay, @squeejay


2 Comments

My National Archives blog: in pursuit of lichen dyes

lichen_edited-1

Specimen page from lichen collection found in Leeds archive, now held in the Economic Botany Collections, Kew. The botanist was J.M. Despréaux.

‘Connecting Collections’ is a series of National Archives blogs by academic researchers, exploring the connections between archives across the UK and around the world Last year The National Archives held a competition inviting researchers to submit guest blogs. When I thought about it, I realised just how many such connections had been made in my early research into the lichen dye trade. My blog just made it on the closing day and I was delighted it it was accepted for publication – on 18th May. The title was A Purple Pursuit and you can read it here:

http://blog.nationalarchives.gov.uk/blog/purple-pursuit/

It is about my research into the history of a Leeds dye manufacturer whose early fortunes were based on a lichen-sourced dye called orchil.

Links

There are several other interesting blogs available at the Connecting Collections page on National Archives site

More on my Wood and Bedford / Yorkshire Chemicals research on this blog:

Tyrian Purple – from a Leeds archive?

Tyrian Treasure: Part One

Tyrian Treasure: Part Two

Dyes, history, and a chilly trip to Yorkshire

A Purple Pursuit
